Device description



Click to enlarge



Click to enlarge

Click to enlarge



A –  Two connectors, marked #1 and #2. These connectors are the interface to the target microcontroller. Depending on the target microcontroller debug features, the supplied ribbon-cables will need to be connected to either connector #1 only or connectors #1 and #2.



B – The indicator lights provide the status of the hardware:



green

Power Indicator

On – Powered on

Off – Powered off



red

R – Running Indicator

On – Target microcontroller is executing code

Off – Target microcontroller is halted



yellow

F –Free Indicator

On – BlueBox is available for a connection from a host PC

Off – Active connection to the BlueBox from a host PC exists



C – The grounding socket (GND) is used together with the  Grounding wire to create an electrical connection between the BlueBox and the target circuitry. The socket is suitable for a 2 mm Multi Contact Plug (Banana Plug) if building a longer or a replacement cable on your own.



D – The FNet Port provides an interface for the TASKING’s range of ADIO & CAN/LIN Accessories.



E – Reset (from revision R13). The Reset button loads the default firmware.



Warning_orange

Use only if advised by the Technical support.



F – 10/100 Ethernet Socket




I – Power Switch



H – Power Supply Socket

The socket and plug are latching to stop the plug from being accidentally pulled out of the socket.

To remove the power plug from the socket, always pull gently of the sleeve of the plug and never on the wire.


G – USB 3.0 Socket

It is highly recommended to use the USB 3.0 cable, because it fulfills the maximum USB 3.0 transfer rate (5Gbit/s). Use of alternate cables must be undertaken at your own risk.



Power-Supply-Socket



Both the 10/100 Ethernet Socket (E) and the USB 3.0 Socket (F) can be connected to a network/PC simultaneously. The active interface will be determined by whichever interface winIDEA connects to first.



Warning_orange

When powering on the system, switch the BlueBox unit on before powering on the Target. When powering down the system, power off the Target before powering off the BlueBox unit!

FBridge port is not Ethernet port!

Use only original accessories for powering and connecting with the BlueBox unit. Consult with Technical support before attempting to use any other accessory.

Differences between BlueBox CI and BlueBox





BlueBox CI

BlueBox

Business Model

Subscription

Perpetual or Subscription

System price

*

***

Debug & Test functionalities via winIDEA GUI

Debug & Test functionalities via SDK APIs
