Mechanical information

Emulation Adapter

Click to enlarge

Side view of the Emulation adapter complete setup - QFP Fixed Adaptation



Click to enlarge

Top view of the Emulation Adapter



Click to enlarge

Top view of the Conversion board





Ordering code

Unit (mm)

M

N

P

R

S

T

V

IEA-TC377TE-TOP

70

70





32.6

36.4

47.5

IEA-TC377TE-xxxxxx





70

70









Solder parts

QFP

Click to enlarge

Solder part Solder pad view



Click to enlarge

Top view of the Solder part





In the case of soldering the Solder part manually, it’s highly recommended to prolong the solder pad E on the outer side (e.g., for 1.5–2 mm) during the PCB design. Note that without this modification, it’s very difficult to solder the Solder part manually.



Recommended PCB footprint dimensions:

Ordering code

Unit (mm)

A

B

C

D

E

K

L

IANQPACK80SE

11.1

11.1

0.2

0.4

1

19

19

IANQPACK100SE

13.1

13.1

0.2

0.4

1

21

21

IANQPACK144SE

17.1

17.1

0.2

0.4

1

25

25

IA144TQ-SOLDER

19.5

19.5

0.25

0.5

1.625

25.05

25.05

IA176TQ-SOLDER

23.5

23.5

0.25

0.5

1.625

29.05

29.05



QFP Flex – Wire adapter

Click to enlarge



Ordering code

Unit (mm)

Q

IEA-TC377TE-TC332W

170

IEA-TC377TE-BTQ100W

170

IEA-TC377TE-TC334W

170

IEA-TC377TE-TC364W4

170

IEA-TC377TE-TC364W5

170

IEA-TC377TE-TC365W5

170

EA-TC377TETC375W5

170



QFP Flex – Flex PCB adapter

Click to enlarge

Ordering code

Unit (mm)

U

V

IEA-TC377TETC375FP5

166

255



Extenders

Click to enlarge

Side view of the Extender



Top view of the Extender

Top view of the Extender





Ordering code

Unit (mm)

W

Z

IA292LFBGA-EXTENDER

17

3.25



i-icon

To view Emulation Adapter schematics, refer to Schematics .
